NatureFlow Ventures provides innovative water treatment solutions with top-tier technology and service, specializing in water and wastewater treatment since 2023.
Imagine a wastewater treatment solution that produces water clean enough for gardening, cooling towers, toilet flushing, and other reuse applications—all while using significantly less space than conventional systems.
At Nature Flow Ventures, we design, manufacture, and install advanced Membrane Bioreactor (MBR) systems for industries, residential complexes, commercial buildings, hotels, and healthcare facilities across India.
That is the power of membrane bioreactor systems.
We are not just technology providers—we are partners in helping businesses and communities achieve sustainable wastewater reuse with confidence.
Traditional wastewater treatment plants typically rely on large settling tanks to separate solids from treated water. This process takes time, occupies significant space, and may not always deliver high-quality effluent.
Membrane bioreactor systems transform this process by replacing traditional settling tanks with advanced hollow fiber membranes.
Think of these membranes as thousands of microscopic filters with ultra-fine pores that allow only purified water to pass while blocking:
At Nature Flow Ventures, we combine biological treatment (where beneficial bacteria naturally break down pollutants) with membrane filtration into a single seamless treatment process.
The result is a membrane bioreactor system that delivers exceptional water quality, low sludge generation, and compact installation.
Compared to traditional Activated Sludge Process (ASP) or MBBR systems, membrane bioreactor systems offer significant advantages:
For organizations focused on water recycling, space optimization, and high-purity treated water, membrane bioreactor systems represent the gold standard in wastewater treatment.
| Parameter | Specification Range |
|---|---|
| Treatment Capacity | 5 KLD to 2000 KLD (Customizable) |
| Membrane Type | Submerged Hollow Fiber Membrane (PVDF Material) |
| Pore Size | 0.02 to 0.04 Microns (UF Range) |
| Membrane Brand | Koch / Mitsubishi / Equivalent Premium Brands |
| Design Flux | 15 to 35 L/m²/hour (Depending on Feed Quality) |
| Inlet Parameters | BOD up to 1000 mg/L, COD up to 2000 mg/L, TSS up to 1000 mg/L |
| Outlet Quality | BOD < 5 mg/L, COD < 30 mg/L, TSS < 5 mg/L, Turbidity < 1 NTU |
| Log Removal Value | > 6 for Bacteria, > 4 for Viruses |
| MLSS Range | 8,000 to 15,000 mg/L |
| Hydraulic Retention Time | 4 to 8 Hours |
| Sludge Yield | 0.1 to 0.3 kg TSS per kg BOD Removed |
| Cleaning System | Automatic Backwash + Periodic Chemical CIP Cleaning |
| Material of Construction | SS304 Tank with SS316 Membrane Frame |
| Automation | Fully Automatic PLC / SCADA with Remote Monitoring |
| Power Supply | 415V, 3-Phase, 50Hz |
For Zero Liquid Discharge (ZLD) applications, our membrane bioreactor systems work as ideal pre-treatment before Reverse Osmosis (RO) plants.
Our membrane bioreactor systems are suitable for multiple sectors and applications:
At Nature Flow Ventures, we understand that advanced treatment technologies can sound intimidating.
That is why we make the process simple:
Our goal is to ensure your membrane bioreactor system performs efficiently from day one and continues delivering value for years.
One of the most common questions is whether membrane bioreactor systems are expensive to operate.
While MBR systems generally consume more power than conventional plants due to aeration and membrane suction, the benefits often outweigh the cost:
At Nature Flow Ventures, we provide transparent operating cost estimates upfront—so there are no surprises later.
You may need a membrane bioreactor system if:
Why settle for ordinary wastewater treatment when you can achieve exceptional water clarity and reuse quality?
With Nature Flow Ventures and our advanced membrane bioreactor systems, wastewater transforms into a valuable, reusable resource.
Contact us today for a free consultation and feasibility study. Let us help you create a smarter, cleaner, and more sustainable future through advanced wastewater treatment.
